11.3 Network operation
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
341
11.3 Network operation
Note
The network function is only available for SINUMERIK 802D sl.
Thanks to the integrated network adapter, the control system is network-capable. The
following connections are possible:
● Ethernet peer-to-peer: Direct connection between control system and PC using a cross-
over cable
● Ethernet network: Integrating the control system into an existing Ethernet network using a
patch cable.
Screened network operation with encrypted data transfer is possible using an 802D specific
transmission protocol. This protocol is used, e.g. for transmitting and executing part
programs in conjunction with the RCS tool.
