Siemens SINUMERIK 802D User Manual

Part programming
7.3 Editing the part program
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
105
Operating sequence
In the PROGRAM MANAGER operating area, select the program to be edited.
Press the "Open" softkey. The selected program will open.
Softkeys
Use this softkey to edit a file.
Use this softkey to execute the selected file.
Use this softkey to select a text segment up to the current cursor position (alternatively:
<CTRL+B>)
Use this softkey to copy a selected block to the clipboard (alternatively: <CTRL+C>)
Use this softkey to paste a text from the clipboard at the current cursor position (alternatively:
<CTRL+V>)
Use this softkey to delete a selected text (alternatively: <XTRL+X>)
Use the "Find" softkey to search for a string in the program file displayed.
Type the term you are looking for in the input line and use the "OK" softkey to start the
search. Use "Cancel" to close the dialog box without starting the search process.
Use this softkey to replace the block numbers from the current cursor position up to the
program end.
See Section entitled
"Cycles" (Page 161)
For recompilation, position the cursor on the cycle calling line in the program. This function
decodes the cycle name and prepares the screenform with the relevant parameters. If there
are any parameters beyond the range of validity, the function will automatically use the
default values. After closing the screenform, the original parameter block is replaced by the
corrected block.
Note
Only automatically generated blocks can be recompiled.
2SHQ
0DFKLQLQJ
([W
H[HFXWLRQ
0DUN
EORFN
&RS\
EORFN
,QVHUW
EORFN
'HOHWH
EORFN
)LQG
5HQXPEHU
*ULQGLQJ
F\FOHV
5HFRPS
