System
8.5 SYSTEM - "PLC" softkeys
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
141
Use the "Status list" function to display and modify PLC signals.
There are 3 lists to choose from:
● Inputs (default setting) left-hand list
● Flags (default setting) center list
● Outputs (default setting) right-hand list
● Variable
Figure 8-38 PLC status list
Use this softkey to change the value of the highlighted variable. Press the "Accept" softkey
to confirm your changes.
6WDWXV
OLVW
&KDQJH
