8.5 SYSTEM - "PLC" softkeys
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
143
This dialog displays all files of the MPF directory and their assignment in the reference list
(PLCPROG.LST) in the form of a list. You can use the TAB key to switch between the two
columns. The Copy, Insert and Delete softkey functions are displayed with reference to a
specific context. If the cursor is placed on the left-hand side, only the Copy function is
available. On the right-hand side, the Insert and Delete functions are provided to modify the
reference list.
List of references for interface signals
SINUMERIK 802D sl Function Manual; Various Interface Signals (A2)
SINUMERIK 802D sl List Manual
Writes the selected file name to the clipboard.
Pastes the file name at the current cursor position.
Deletes the selected file name from the assignment list.
Structure of the reference list (file PLCPROG.LST)
It is divided into 3 areas:
Number range Protection level
1 to 100 User area User
101 to 200 Machine manufacturer Machine manufacturer
201 to 255 Siemens Siemens
The notation is carried out for each program by lines. Two columns are intended per line,
which must be separated from each other by TAB, space or the "|" character. In the first
column, the PLC reference number must be specified, and in the second column, the file
name.
Example:
1 | shaft.mpf
2 | taper.mpf
