Programming
10.7 Miscellaneous function M
Cylindrical grinding
302 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
Note
In addition to M and H functions, T, D, and S functions can also be transferred to the PLC
(programmable logic controller). In all, a maximum of 10 such function outputs are possible
in a block.
Information
With the SINUMERIK 802D sl plus and 802D sl pro, two spindles are possible. This results in
an expanded programming capability for the M commands - only for the spindles:
M1=3, M1=4, M1=5, M1=40, ... ; M3, M4, M5, M40, ... for spindle 1
M2=3, M2=4, M2=5, M2=40, ... ; M3, M4, M5, M40, ... for spindle 2
