Define
4.1 Entering tools and tool offsets
Cylindrical grinding
36 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
Softkeys
Clearing the calculated dresser data.
Use this softkey to delete the tool.
Opens a lower-level menu bar offering all functions required to create and display further
tolol data.
This function is used to enter - guided by the menu - the nomiinal dimensions and monitoring
data of the grinding wheel.
This function is used the enter the wheel geometry for the wheel type selected.
This function is used the enter the dressing technology for dressing the wheel type selected.
This function is used to enter/verify the dresser data of the first dresser.
For dressers 2 and 3, it is selected through the respective softkeys.
This function is used to enter/verify all tool data (D1 through D9).
Use this function to copy an already existing tool.
Use this function to search for a tool by its number.
Use this softkey to create tool compensation data for a new tool.
This function is used to list and, if necessary, modify any R parameters that exist in the
control system.
Input of the setting data.
This function is used to list and, if necessary, modify any user grinding data that exists in the
controller.
