PLC diagnostics
13.2 Operating options
Cylindrical grinding
370 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
Use this softkey to display the list of cross references. All operands used in the PLC project
are displayed.
This list indicates in which networks an input, output, flag etc. is used.
Figure 13-14 Cross references main menu (absolute)
Figure 13-15 Cross references main menu (symbolic))
You can open the appropriate program segment directly in the 1/2 window using the "Open
in Window 1" or "Open in Window 2" function.
&URVV
UHIV
2SHQLQ
ZLQGRZ
