Siemens SINUMERIK 802D User Manual

Application Examples
14.2 Cycle example 2
Cylindrical grinding
376 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
Table 14- 2 Programming
Program block Explanation
N10 T1 D2 M23
N20 CYCLE420( 160, 0.02, 0.005, 0.005, 0.15,
0.15, 0.15, 0.15, 0.15, 10, 20, 20, 0, , , , 1,
5)
Basic data
N30 CYCLE413( 0, 160.1, -160, -45, 3, ,0.1,
0.03, 0.010, 0.8, 0.3, 1, 1, 0, 0, 5)
Right-hand oblique plunge-cutting
N40 T1 D2
N50 CYCLE412( 0, -160, 170, 3, 0.1, 0.1, 0.05,
1, 0.5, 1, 0, 5, 10, 2000)
Right-hand face plunge-cutting
N60 T1 D4
N70 CYCLE411( 0, 160.1, -161, -
2
60, 5, 1, ,0.4,
0.03, 0.01, 0.01, 0.005, 0, 1, 1, 3000, 0.8,
0.8, 0.80, 1, 0, 0, 5)
Multiple plunge-cutting, only
roughing from right to left
N80 CYCLE415( 0, 160, -161, -260, 3, ,0.04,
0.03, 0.01, 0.02, 0.01, 0.005, -1, 1, 1, 3000,
4000, 5000, 1, 1, 1, 2, 0, 0, 5)
Longitudinal grinding from right to
left
N90 T1 D3
N100 CYCLE410( 0, 180, -161, 3, ,0.1, 0.03,
0.01, 0.8, 0.1, 0.2, 1, 0, 0, 5, 5, 1000)
Oscillating plunge-cutting
N110 T1 D5
N120 CYCLE412( 0, -130, 176, 3, ,0.10, 0.03,
0.1, 0.1, 1, 0, 5, 10, 1000)
Oscillating face plunge-cutting
N130 T1 D3
N140 CYCLE410( 0, 170, -124, 3, ,0.1, 0.03,
0.01, 0.80, 0.1, 0.08, 1, 0, 0, 5, ,)
Plunge-cutting
N150 T1 D1
N160 CYCLE413( 0, 160, -
1
00, 45, 3, ,0.1, 0.03,
0.01, 0.8, 0.1, 0.08, 1, 0, 0, 5)
Left-hand oblique plunge-cutting
N170 T1 D2
N180 CYCLE411( 0, 150.1, 0, -70, 50, 1, ,0.1,
0.03, 0.01, 0.01, 0.05, 1, 1, 1, 3000, 1, 1, 1,
0, 0, 0, 5)
Multiple plunge-cutting, only
roughing from right to left
N190 CYCLE411( 0, 150, 0, -70, 5, 2, ,0.1,
0.03, 0.01, 0.01, 0.05, 1, 1, 1, 3000, 1, 1, 1,
0, 0, 0, 5)
Multiple plunge-cutting, only
finishing/fine finishing (two-step
longitudinal grinding) from right
to left
N200 M9 M17
