A.2 Parameter tables of the tool data
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
381
Tx Dy DP16 REAL Diameter dressing amount (µm)
Tx Dy DP17 REAL Dresser wear X (µm) diameter
Tx Dy DP18 REAL Dresser wear Z (µm) diameter
Tx Dy DP19 REAL Dressing direction (drawing/plunging) diameter
Tx Dy DP20 REAL Path feedrate (mm/rev) diameter
Tx Dy DP21 REAL Additional compens. in X, diameter, basic dimension
Tx Dy DP22 REAL Additional compens. in Z, length in Z, basic dimension
Tx Dy DP23 REAL (reserved, length 3)
Tx Dy DP24 REAL Diameter compensation of measurement control or cutting edge 1-6
initial dimension
Tx Dy DP25 REAL Z compensation of measurement control or initial dimension of each
cutting edge
Tx Dy DPC1 REAL Left/right overrun
Tx Dy DPC2 REAL Left/right radius
Tx Dy DPC3 REAL Left/right X chamfer
Tx Dy DPC4 REAL Left/right Z chamfer
Tx Dy DPC5 REAL Left/right shoulder height
Tx Dy DPC6 REAL Left/right back-slope angle
Tx Dy DPC7 REAL Left/right back-slope height
Tx Dy DPC8 REAL X overrun
Tx Dy DPC9 REAL Usable wheel width
Tx Dy DPC10 REAL No. of contour program
Table A- 3 3. Cutting edge for grinding wheel
Tx Dy DP1 INT Tool type=403
Tx Dy DP2 INT Cutting edge position (1...9)
Tx Dy DP3 REAL D - Diameter of the new wheel
Tx Dy DP4 REAL L - Distance of the wheel reference point
Tx Dy DP5 REAL (reserved, length 3)
Tx Dy DP6 REAL R - Tool nose radius
Tx Dy DP7 REAL Coasting revolutions
Tx Dy DP8 REAL Profile roller plunge feed (wheel types 5 and 6)
Tx Dy DP9 REAL Profile roller dressing feed (wheel types 5 and 6)
Tx Dy DP10 REAL GWPS profile roller (wheel types 5 and 6)
Tx Dy DP11 REAL Profile roller GWPS ratio (wheel types 5 and 6)
Tx Dy DP12 REAL dD - Change in diameter (dressing amount X)
Tx Dy DP13 REAL dL - Change in distance (dressing amount Z)
Tx Dy DP14 REAL (Length 3)
Tx Dy DP15 REAL dR - Change in tool nose radius (radius wear)
Tx Dy DP16 REAL Profile roller dressing number (wheel types 5 and 6)
Tx Dy DP17 REAL Reserved
