Define
4.6 Sense probe
Cylindrical grinding
Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
53
The values for the setting value (position in Z axis), feedrate, and approach direction are
entered into the input screen.
Press the "Set position" softkey to set up the measuring position.
The Z axis feeds in probe direction until the workpiece is touched. This position is set as a
value and the probe retracts.
After a confirmation, the X axis traverses to its retract position and the probe swings out.
The positions determined are taken into account in CYCLE420 if longitudinal alignment has
been enabled. For this, the X measuring position is approached and the Z position can be
selected within the cycle.
Note
Both calibration and measurement must always be done in the same direction.
The function can be interrupted.
Exit the function.
6HW
SRVLWLRQ
%DFN
