Siemens SINUMERIK 802D User Manual

Manual mode
5.2 JOG mode - "Position" operating area
Cylindrical grinding
68 Programming and Operating Manual, 07/2009, 6FC5398-4CP10-2BA0
Softkeys
Note
An explanation of the vertical softkeys can be found in the section on the
MDA mode
(Page
70).
This function is for grinding (precision grinding) with the handwheel. This function does not
require a workpiece program.
This function is used to determine the dresser positions in the machine for dressers that are
used by means of the geometry axes.
This function is used to detect the workpiece position in the machine with respect to the
particular axis.
This function is used to shape a "raw" grinding wheel without generating an NC program.
This function is used to set the measuring position of the probe. The measuring position is
set up for each particular workpiece
Note
The parameters within the "Settings" function do not affect grinding.
Use this softkey to switch between the metric and the inch dimension systems
0DQXDO
JULQG
6HQVH
GUHVVHU
6HQVH
ZRUNSLHFH
6KDSLQJ
6HQVH
SUREH
6HWWLQJV
6ZLWFK
PP!LQFK
