No. Parameter
mask
Parameter
internal
Data type Meaning
26 <_UMODE> INT Reserved
27 FS <_FS> REAL Chamfer width (inc) for chamfering
28 ZFS <_ZFS> REAL Insertion depth (tool tip) on chamfering (abs/inc), see <_AMODE>
29 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Reserved
HUNDREDS: Select machining or just calculation of
start point
1 = Normal machining
THOUSANDS: Dimensioning of reference point, slot
length
0 = Center
1 = Inner left-hand +L
2 = Inner right-hand -L
3 = Left-hand edge +L
4 = Right-hand edge -L
30 <_DMODE> INT Display mode
UNITS: Machining plane G17/18/19
0 = Compatibility, the plane effective
before the cycle call remains ac‐
tive
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
TENS: Reserved
HUNDREDS: Reserved
THOUSANDS: Software version identification
1 = Function extension SLOT1
TEN THOUSANDS: Technology scaling in cycle screen forms
(Page 1153)
0 = Input: Complete
1 = Input: Simple
31 <_AMODE> INT Alternative mode
UNITS: Final depth Z1 (abs/inc)
0 = Compatibility
1 = Z1 (inc)
2 = Z1 (abs)
TENS: Reserved
HUNDREDS: Insertion depth for chamfering ZFS
0 = ZFS (abs)
1 = ZFS (inc)
Work preparation
3.25 Programming cycles externally
NC programming
1036 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
