4.3.27 G group 27: Tool offset for change in orientation at outside corners
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
ORIC 1 Orientation changes at outside corners are superim‐
posed on the circle block to be inserted
+ m x
ORID 2. Orientation changes are performed before the circle
block
+ m
4.3.28 G group 28: Working area limitation
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
WALIMON 1 Working area limitation ON + m x
WALIMOF 2 Working area limitation OFF + m
4.3.29 G group 29: Radius/diameter programming
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
DIAMOF 1 Modal channel-specific diameter programming OFF
Deactivation activates channel-specific radius pro‐
gramming.
+ m x
DIAMON 2 Modal independent channel-specific diameter pro‐
gramming ON
The effect is independent of the programmed dimen‐
sions mode (G90/G91).
+ m
DIAM90 3 Modal dependent channel-specific diameter program‐
ming ON
The effect is dependent on the programmed dimen‐
sions mode (G90/G91).
+ m
DIAMCYCOF 4 Modal channel-specific diameter programming during
cycle processing OFF
+ m
4.3.30 G group 30: NC block compression
G command No.
1)
Meaning MD20150
2)
W
3)
STD
4)
SAG MH
COMPOF 1 NC block compression OFF +/- m x
COMPON 2 Compressor function COMPON ON +/- m
Tables
4.3 G commands
NC programming
1256 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
