No. Parameter
mask
Parameter
internal
Data type Meaning
5 <_DPR> REAL Long hole depth (inc) with respect to Z0 (enter without sign)
6 <NUM> INT Number of long holes = 1
7 L <LENG> REAL Length of long hole
8 X0 <_CPA> REAL Reference point 1st axis of the plane
9 Y0 <_CPO> REAL Reference point 2nd axis of the plane
10 <RAD> REAL Reserved
11 α0 <STA1> REAL Angle of rotation
12 <INDA> REAL Reserved
13 FZ <FFD> REAL Depth infeed rate
14 F <FFP1> REAL Feedrate
15 DZ <MID> REAL Maximum depth infeed
16 <_VARI> INT Machining type
UNITS: Infeed type
1 = Vertically with G1
3 = Oscillation
HUNDREDS: Reserved
17 <_UMODE> INT Reserved
18 <_GMODE> INT Geometrical mode (evaluation of programmed geometrical data)
UNITS: Reserved
TENS: Reserved
HUNDREDS: Select machining or just calculation of
start point
0 = Compatibility mode
1 = Normal machining
THOUSANDS: Dimensioning of reference point, slot
length
0 = Center
1 = Inner left-hand +L
2 = Inner right-hand -L
3 = Left-hand edge +L
4 = Right-hand edge -L
Work preparation
3.25 Programming cycles externally
NC programming
1040 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
