Param‐
eter
mask
Parameter
internal
Data type Prog. for form Meaning
8 X1 <_EPD> x x - - Allowance X (abs/inc), see <_AMODE>
- - - x Undercut depth (abs/inc), see <_AMODE>
9 Z1 <_EPL> - x - - Allowance Z
- - - x Undercut width (abs/inc), see <_AMODE>
10 R1 <_R1> - - - x Rounding radius on slopes
11 R2 <_R2> - - - x Rounding radius in the corner
12 α <_STA> - - x x Insertion angle
13 VX <_VRT> x x - - Cross-feed X (abs/inc), see <_AMODE>
- - x x Cross-feed X when finishing, (abs/inc), see <_AMODE>
14 D <_MID> - - x x Depth infeed
15 U <_FAL> - - x x Finishing allowance parallel to contour, see <_AMODE>
16 UX <_FALX> - - x x Finishing allowance X
17 UZ <_FALZ> - - x x Finishing allowance Z
18 P <_PITI> INT - - x - Select pitch, form A-D, corresponds to M1 ... M68
0 = 0.20
1 = 0.25
2 = 0.30
3 = 0.35
4 = 0.40
5 = 0.45
6 = 0.50
7 = 0.60
8 = 0.70
9 = 0.75
10 = 0.80
11 = 1.00
12 = 1.25
13 = 1.50
14 = 1.75
15 = 2.00
16 = 2.50
17 = 3.00
18 = 3.50
19 = 4.00
20 = 4.50
21 = 5.00
22 = 5.50
23 = 6.00
x x - - Select radius/depth, form E, F
0 = 0.6 x 0.3
1 = 1.0 x 0.4
2 = 1.0 x 0.2
3 = 1.6 x 0.3
4 = 2.5 x 0.4
5 = 4.0 x 0.5
6 = 0.4 x 0.2
7 = 0.6 x 0.2
8 = 0.1 x 0.1
9 = 0.2 x 0.1
19 <_PTAB> STRING
[5]
String for thread table ("", "ISO", "BSW", "BSP", "UNC")
(for the surface only)
20 <_PTABA> STRING
[20]
String for selection from thread table
(e.g. "M 10", "M 12", ...)
(for the surface only)
21 <_DMODE> INT Display mode
x x x x UNITS: Machining plane G17/G18/G19
0 = Compatibility, the plane effec‐
tive before the cycle call re‐
mains active
1 = G17 (only active in the cycle)
2 = G18 (only active in the cycle)
3 = G19 (only active in the cycle)
