No. Screen
form param‐
eter
Cycle pa‐
rameter
Meaning
2 Selection S_KNUM Correction of work offset (WO) or basic WO or basic reference
2)
Val‐
ues:
UNITS:
TENS:
0 = No correction
1 to max. 99 numbers of the work offset or
1 to max. 16 numbers of the basic offset
HUNDREDS: Reserved
THOUSANDS: Correction of WO or basic or basic reference
0 = Correction of the adjustable WO
1 = Correction of the channel-specific basic WO
2 = Correction of the basic reference
3 = Correction of the global basic WO
9 = Correction of the active WO or for G500 in last active channel-specific basic WO
TEN THOUSANDS: Coarse or fine correction in the WO, basic WO or basic refer‐
ence
0 = Fine correction
6)
1 = Coarse correction
Work preparation
3.25 Programming cycles externally
NC programming
1172 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
