Table 3-22 CYCLE971 call parameters
1)
No. Screen
form pa‐
rameter
Cycle pa‐
rameter
Meaning
1 S_MVAR Measuring variant
Val‐
ues:
UNITS:
0 = Calibrate tool probe
1 = Measure tool with stationary spindle (length or radius)
2 = Measure tool with rotating spindle (length or radius), see parameters S_F1
to S_S4
TENS: Measurement in the machine coordinate system or workpiece coordinate
system
0 = Measurement in MCS (machine-related), measure tool or calibrate tool probe
1 = Measurement in WCS (workpiece-related), measure tool or calibrate tool probe
HUNDREDS: Individually check teeth
0 = No
1 = Yes
THOUSANDS:
0 = 0
TEN THOUSANDS: Incremental calibration or measurement
0 = No specification
1 = Incremental calibration or measurement
HUNDRED THOUSANDS: Calibrate tool probe automatically
0 = Do not calibrate tool probe automatically
1 = Calibrate tool probe automatically
ONE MILLION: Calibrating in the plane with spindle reversal
0 = Calibrating in the plane without spindle reversal
1 = Calibrating in the plane with spindle reversal
2 Selection S_KNUM Offset variant
2)
Val‐
ues:
UNITS: Tool offset
0 = No specification (tool offset in geometry)
1 = Tool offset in wear
3 Icon+
number
S_PRNUM Number of the field of the probe parameters (not probe number)
4 X0 S_MA Measuring axis, offset axis
4)
Val‐
ues:
UNITS: Number of the measuring axis
1 = 1st axis of the plane (for G17 X)
2 = 2nd axis of the plane (for G17 Y)
3 = 3rd axis of the plane (for G17 Z)
TENS:
0 = 0
HUNDREDS: Number of the offset axis
0 = Not an offset axis
1 = 1. axis of the plane (for G17 X)
2 = 2nd axis of the plane (for G17 Y)
Work preparation
3.25 Programming cycles externally
NC programming
1192 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0
