Siemens SINUMERIK 840D sl Programming Manual

Address iden‐
tifier (default
setting)
Address type Modal/
non-
modal
G90/
G91
IC AC DC,
ACN,
ACP
CIC,
CAC,
CDC,
CACN,
CACP
PR,
PM
QU Max.
num‐
ber
Data type of the
assigned value
Corner rounding criteria
ADIS Rounding clear‐
ance
m 1 Unsigned
REAL
ADISPOS Rounding clear‐
ance for rapid
traverse
m 1 Unsigned
REAL
Measurement
MEAS Measurement
with touch-trig‐
ger probe
s 1 Unsigned
INT
MEAW Measurement
with touch-trig‐
ger probe with‐
out deletion of
distance-to-go
s 1 Unsigned
INT
Axis, spindle behavior
LIMS Spindle speed
limitation
m 1 Unsigned
REAL
COARSEA Block change
behavior: Exact
stop coarse axial
m
FINEA Block change
behavior: Exact
stop fine axial
m
IPOENDA Block change
behavior: Inter‐
polator stop axial
m
DIACYCOFA Transverse axis:
Axial diameter
programming
OFF in cycles
m
DIAM90A Transverse axis:
Axial diameter
programming for
G90
m
DIAMCHAN Transverse axis:
Transfer of all
transverse axes
in the diameter
programming
channel status
m
Tables
4.2 Addresses
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1243

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
