Siemens SINUMERIK 840D sl Programming Manual

Address iden‐
tifier (default
setting)
Address type Modal/
non-
modal
G90/
G91
IC AC DC,
ACN,
ACP
CIC,
CAC,
CDC,
CACN,
CACP
PR,
PM
QU Max.
num‐
ber
Data type of the
assigned value
Tool selection
TCARR Tool carrier m 1 INT
Tool management
DL Total tool offset m 1 INT
OEM addresses
OMA1 OEM address 1 m x x x 1 REAL
OMA2 OEM address 2 m x x x 1 REAL
OMA3 OEM address 3 m x x x 1 REAL
OMA4 OEM address 4 m x x x 1 REAL
OMA5 OEM address 5 m x x x 1 REAL
Miscellaneous
CUTMOD Modification of
the offset data
for rotatable
tools (in combi‐
nation with ori‐
entable tool car‐
riers)
m INT
CUTMODK Modification of
the offset data
for rotatable
tools (in combi‐
nation with orien‐
tation transfor‐
mations that
have been de‐
fined by means
of kinematic
chains)
m STRING
TOFF Tool length off‐
set parallel to
the specified ge‐
ometry axis
m REAL
TOFFL Tool length off‐
set in the direc‐
tion of the tool
length compo‐
nent
L1, L2 or L3
m REAL
Tables
4.2 Addresses
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 1245

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
