Siemens SINUMERIK 840D sl Programming Manual

6WDUWLQJSRLQW
(QGSRLQW
&HQWHUSRLQW
[

]

$5
.5
,5
.

Figure 2-11 Convex thread in the clockwise direction with center point and opening angle programming
Example 6: Convex thread in the clockwise direction with end and intermediate point
programming
Program code
N5 G0 G18 X50 Z50
N10 G335 Z100 K=3.5 I1=60 K1=64
6WDUWLQJSRLQW
(QGSRLQW
,QWHUPHGLDWH
SRLQW
&HQWHUSRLQW
[

]
.
.
,

Figure 2-12 Convex thread in the clockwise direction with end and intermediate point programming
Fundamentals
2.9 Motion commands
NC programming
238 Programming Manual, 12/2019, 6FC5398-2EP40-0BA0

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
