Examples:
● External program memory:
– //Drive1:
– //Drive_1:
– //Drive 1:
– //A B:
– //1 B C 2:
Directory path
The following rules govern the specification of the directory path:
● A "/" is located at the start and end of the directory path and as separator for the individual
path sections.
Note
A double slash ("//") within the directory path is not permitted!
● Directory names:
– Directory names must begin with a letter or a digit. Only for addressing in the NC notation
do directory names begin with the domain identification "_N_".
– The following characters can be any combination of letters, digits and "_".
Note
Spaces in directory names are also permitted for external program memories. This is not
true, however, when the external program memory is created as global part program
memory (GDIR).
– Other special characters are not permitted.
● Directory extensions:
– Directory extensions must consist of three letters/digits.
– They are separated with "_" (NC notation) or "." (EES notation) from the directory name.
Note
The passive file system has only the directory extensions _DIR and _WPD.
Work preparation
3.4 File and Program Management
NC programming
Programming Manual, 12/2019, 6FC5398-2EP40-0BA0 557

Siemens SINUMERIK 840D sl Specifications

General

Control Type	CNC
Number of Axes	Up to 31
Max Number of Channels	10
Interfaces	Ethernet, PROFIBUS, PROFINET, USB
Interpolation	5-axis interpolation
Operating Temperature	0°C to 45°C
Relative Humidity	Up to 95% (non-condensing)
Display	TFT color display, various sizes
Programming Languages	DIN/ISO
Safety Features	Safety Integrated
PLC	Integrated PLC S7-300
Drive Interface	SINAMICS S120
Data Storage	CF card, USB
Operating System	Windows-based
