Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
234 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Direction keys rapid traverse override
The transfer is dependent upon the selected axis. The associated interface bits are deleted
for axes, which are not selected.
Source:
MCP button
Destination:
Interface DB (Parameter ChanNo)
Direction key + DB21, ... DBX12.7
Direction key - DB21, ... DBX12.6
Rapid traverse override DB21, ... DBX12.5
Direction key + DB21, ... DBX16.7
Direction key - DB21, ... DBX16.6
Rapid traverse override DB21, ... DBX16.5
Direction key + DB21, ... DBX20.7
Direction key - DB21, ... DBX20.6
Rapid traverse override DB21, ... DBX20.5
Source:
MCP key
Destination:
Interface DB (all axis DBs)
Direction key + DB31, ... DBX4.7
Direction key - DB31, ... DBX4.6
Rapid traverse override DB31, ... DBX4.5
Override
Source:
MCP-Switch
Destination:
Interface DB (parameter ChanNo)
Feedrate override DB21, ... DBB4
Source:
MCP-Switch
Destination:
Interface DB (all axis DBs)
Feedrate override DB31, ... DBB0 (selected axis number) The feed
override of the 1st MCP applies to all axes.
Spindle override DB31, ... DBB19 (parameter SpindleIFNo)
