2.4 Frames

Basic logic functions: Axes, coordinate systems, frames (K2)

68 Function Manual, 11/2006, 6FC5397-0BP10-2BA0

2.4.4.3 Manual traverse in the SZS coordinate system

Previously, geometry axes have been traversed manually in JOG mode in the WCS. In

addition, there is also the option to carry out this manual operation in the SZS coordinate

system. The $AC_JOG_COORD variable enables the user to switch between manual

traversing in the WCS and SZS. The user can now select if he wants to traverse in the SZS

or the WCS.
