Detailed description
2.4 Frames
Basic logic functions: Axes, coordinate systems, frames (K2)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
61
2.4.2.8 Coordinate transformation
0LUURULQJ
5RXJKRIIVHW
)LQHRIIVHW
6FDOLQJ
5RWDWLRQ
The formulae below are used to discover the coordinate transformation for geometry axes:
Y LQY0LQY6LQY5YW
%.6쟦:.6
Y 560YಫW
:.6쟦%.6
V: Position vector in BCS
V': Position vector in WCS
2.4.3 Frames in data management and active frames
2.4.3.1 Overview
There are various types of frame: system frames, basic frames, settable frames and the
programmable frame. Apart from the programmable frame, all types have a frame in the data
management and an active frame. The programmable frame is only active. Frames in the
data management are stored in the static NC memory and can be archived. The program
can describe both data management frames and active frames. HMI can only describe data
management frames.
