Detailed description

2.7 Program operation mode

Basic logic functions: Mode group, channel, program operation, reset response (K1)

Function Manual, 11/2006, 6FC5397-0BP10-2BA0

107

2.7.8 Part-Program Start

Start handling

Table 2-5 Typical program sequence

Sequence Command Conditions

(must be satisfied before the

command)

Comments

1 Load program (via the operator

interface or part program)

2 Select AUTOMATIC mode

3 Program preselection Channel preselected

Preselected channel in

RESET state

User ID sufficient for

program preselection

4 NC start for preselected channel NC start disable not

available

Reference point approached in

all

axes

5 Program execution

6 M02/M30/RESET None End of program
