Detailed description
2.9 Program control
Basic logic functions: Mode group, channel, program operation, reset response (K1)
148 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
2.9.1 Function selection (via operator panel front or PLC)
Operator interface or PLC
The user can control part program execution via the operator panel front or PLC.
Selection, activation, feedback
Selection
Different functions are available under the Program control soft key. Selection affects an
interface signal in the PLC. These signals are to be understood as selection signals from the
operator interface, and do not activate the selected function.
Activation
These signal states must be transferred to another area of the data block to activate the
selected function. With program control by the PLC the signals are to be set directly.
Feedback
The activated functions are partly signaled back to the PLC from the NCK.
Table 2-11 Program control: Interface signals
Function Selection signal Activation signal Feedback signal
SKP skip block 0 to 7
SKP skip block 8 to 9
DB21, ... DBX26.0 - 26.7
DB21, ... DBX27.0 - 27.1
DB21, ... DBX2.0 - 2.7
DB21, ... DBX31.6 - 31.7
- - -
DRY dry run feedrate DB21, ... DBX24.6 DB21, ... DBX0.6 DB21, ... DBX318.6
ROV Rapid traverse override DB21, ... DBX25.3 DB21, ... DBX6.6 - - -
Single block: Preselection of SBL1, SBL2 or SBL3 via program control display of HMI
SBL1: Action single block
SBL2: Decoding single block
SBL3: In cycle
HMI operator panel DB21, ... DBX0.4 - - -
M01 (Programmed stop) DB21, ... DBX24.5 DB21, ... DBX0.5 DB21, ... DBX32.5
Associated M01 DB21, ... DBX24.4 DB21, ... DBX30.5 DB21, ... DBX318.5
DRF selection DB21, ... DBX24.3 DB21, ... DBX0.3 DB21, ... DBX33.3
PRT program test DB21, ... DBX25.7 DB21, ... DBX1.7 DB21, ... DBX33.7
References:
/FB1/Function Manual Basic Functions; NC/PLC Interface Signals (Z1)
/BAD/ Operation Manual HMI Advanced "Operating Area, Machine"
