Siemens SINUMERIK 840D Function Manual

Data lists
5.2 Signals
Basic logic functions: Reference Point Approach (R1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
61
5.2 Signals
5.2.1 Signals to BAG
DB number Byte.Bit Name
11 0.7 Mode group RESET
11 1.2 Machine function REF
5.2.2 Signals from BAG
DB number Byte.Bit Name
11 5.2 Active machine function REF
5.2.3 Signals to channel
DB number Byte.Bit Name
21, ... 1.0 Activate referencing
21, ... 28.7 OEM channel signal (HMI → PLC) REF
5.2.4 Signals from channel
DB number Byte.Bit Name
21, ... 33.0 Referencing active
21, ... 35.7 Reset
21, ... 36.2 All axes referenced

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
