Detailed description

2.12 Block descriptions

Basic logic functions: PLC Basic program powerline (P3 pl)

246 Function Manual, 11/2006, 6FC5397-0BP10-2BA0

7: Update control signals to axes:

The purpose of function 7 is to transmit important control signals at high speed in between

cyclic data transfers. The data byte 4 of application interface DB31 to DB61 is transferred to

the NC. The transfer is performed for all activated axes. This function can be used, for

example, to transfer a feed stop outside the PLC cycle.

The following signals are relevant:

Signal Type Type Value range Remark

Enable I BOOL 1= FC 21 active

Funct I BYTE 7 7: Control signals to axes

S7Var I ANY S7 data storage area Not used

IVAR1 I INT 0

Error A BOOL

ErrCode A INT 1: "Funct" invalid

Function Manual - Basic Functions1
