2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
248 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
MagNo[2].AnzPlatz:=12; //Number of locations for magazine 2 = 12
END_DATA_BLOCK
Note
For further details on tool management (also with regard to PLC) refer to the Description of
Functions Tool Management. Furthermore, PI services are provided for tool management via
the FB 4, FC 7 and FC 8 (see also the corresponding Sections in this documentation).
Declaration of the function
STL representation
FUNCTION FC 22: VOID
// NAME:
TM_DIR
VAR_INPUT
MagNo: INT ;
ReqPos: INT ;
ActPos: INT ;
Offset: BYTE ;
Start: BOOL ;
END_VAR
VAR_OUTPUT
Cw: BOOL ;
Ccw: BOOL ;
InPos: BOOL ;
Diff: INT ;
Error : BOOL ;
END_VAR
BEGIN
END_FUNCTION

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
