Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
213
Signal Typ
e
Type Range of values Remark
AxisNo I INT 1 - 31 No. of axis/spindle to be traversed
Pos I REAL ∓ 0,1469368 I -38
to
∓ 0,1701412 I +39
Rotary axis: Degrees
Indexing axis: Indexing position
Linear axis: mm or inches
FRate I REAL ∓ 0,1469368 I -38
to
∓ 0,1701412 I +39
Rotary axis and spindle: rev/min
See under table containing info about FRate
InPos
Q
BOOL 1 = Position reached,
or function executed
Error A BOOL 1 = error
State
Q
BYTE 0 to 255 Error code
FRate
The feed rate in FC 18 can also be specified as:
1. Cutting rate with unit m/min or feet/min
2. Constant grinding wheel surface speed in m/s or feet/s
These alternative velocity settings can be used only if this function is activated by the NC
program. Checkback signals for successful activation can be found in byte 84 on the axis
interface.
