Detailed Description
2.8 Special handling of tool compensations
Basic logic functions: Tool Offset (W1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
133
Note
In the following description, the wear includes the total values of the following
components:
• Wear values: $TC_DP12 to $TC_DP20
• Sum offset, consisting of:
– Wear values: $SCPX3 to $SCPX11
– Setup values: $ECPX3 to $ECPX11
You will find detailed information about sum and tool offsets in:
References:
/FBW/ Function Manual Tool Management
/PG/ Programming Manual Fundamentals; Tool Compensations
Required setting data
• SD42900 $SC_MIRROR_TOOL_LENGTH (mirroring of tool length components and
components of the tool base dimension)
• SD42910 $SC_MIRROR_TOOL_WEAR (mirroring of wear values of tool length
components)
• SD42920 $SC_WEAR_SIGN_CUTPOS (sign evaluation of the wear components)
• SD42930 $SC_WEAR_SIGN (inverts the sign of the wear dimensions)
• SD42940 $SC_TOOL_LENGTH_CONST (allocation of the tool length components to the
geometry axes)
• SD42950 $SC_TOOL_LENGTH_TYPE (allocation of the tool length components
independent of tool type)
• SD42935 $SC_WEAR_TRANSFORM (transformation of wear values)
• SD42960 $SC_TOOL_TEMP_COMP (tool length offsets)
