Detailed Description
2.9 Mode group, channel, program operation, reset response (K1)
Basic logic functions: NC/PLC interface signals (Z1)
84 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
DB11, ...
DBX4.1
Selected mode MDA
Signal status 0 or
edge change
1 → 0
MDA mode is not selected by HMI.
DB11, ...
DBX4.2
Data block
Selected JOG mode
Signal(s) from BAG (HMI → PLC)
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
JOG mode is selected by HMI.
Signal status 0 or
edge change
1 → 0
JOG mode is not selected by HMI.
DB11, ...
DBX5.0
Selected machine function TEACH IN
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The machine function TEACH IN is selected by HMI within BAG.
Signal status 0 or
edge change
1 → 0
The machine function TEACH IN is not selected by HMI.
Additional
References
/BA/ Operations Guide HMI (corresponding to the used software)
DB11, ...
DBX5.1
Selected REPOS machine function
Edge evaluation: no Signal(s) updated: cyclic
Signal state 1 or
edge change
0 → 1
The machine function REPOS is selected by HMI within BAG.
Signal status 0 or
edge change
1 → 0
The machine function REPOS is not selected by HMI.
Application
example(s)
When a fault occurs when executing a part program (e.g. tool breakage), the axis is manually
moved away from the fault location in the JOG mode in order to be able to replace the tool.
The axis can then be manually returned to the exact previous position using the REPOS machine
function so that the program can be continued in the automatic mode.
Additional references /BA/ Operations Guide HMI (corresponding to the used software)
