Detailed Description
2.1 General functionality
Basic logic functions: Travel to fixed stop (F1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
17
Search process with FXS and FOC
The user selects FXS or FOC in a program area of the searched target block in order to
acquire all states and functions of this machining last valid. The NC will start the selected
program in Program test mode automatically. After the target block has been found, the NC
stops at the beginning of the target block, deselects Program test internally again and
displays the Stop condition "Search target found" in its block display.
If FXS "travel to fixed stop" is located between the beginning of the program and the search
target, the instruction is not really executed by the NC. The motion is only simulated up to
the programmed end point.
Caution
SERUPRO approach does not really take the statementFXS into account. The approach to
the programmed end position of the FXS block is only simulated without torque limitation.
The user can log the turning on and turning off of FXS in the parts program. If necessary, the
user can start an ASUB in order to activate or deactivate FXS in this SERUPRO-ASUP.
$AA_FXS and $VA_FXS
In SW 6.2 and higher, the meaning of system variable $AA_FXS is redefined for SERUPRO
only and completely replaced by variable $VA_FXS. Variables $AA_FXS and $VA_FXS have
the same values continuously outside the SERUPRO function.
Description NCK Variables
Axis not at fixed stop $AA_FXS = 0 and $VA_FXS = 0
Fixed stop successfully approached $AA_FXS = 1 and $VA_FXS = 1
Approach to fixed stop failed $AA_FXS = 2 and $VA_FXS = 2
Travel to fixed stop selection active $AA_FXS = 3 and $VA_FXS = 3
Fixed stop detected $AA_FXS = 4 and $VA_FXS = 4
Travel to fixed stop deselection active $AA_FXS = 5 and $VA_FXS = 5
