Detailed description

2.2 Metric /inch measuring system

Basic logic functions: Velocities, Setpoint/Actual Value Systems, Closed-Loop Control (G2)

Function Manual, 11/2006, 6FC5397-0BP10-2BA0

N270 A10

; Feedrate=100 degrees/min

; Path=10 degrees

; R7=6 s approx.

N280 DO $R8=$AC_TIME

N290 X0.001 A10

; Feedrate=2540 mm/min

; Path=10 mm

; R8=0.288 s approx.

N300 FGREF[A]=360/(2*$PI)

; Set 1 degree=1 inch via the effective radius

N310 DO $R9=$AC_TIME

N320 X0.001 A10

; Feedrate=2540 mm/min

; Path=254 mm

; R9=6 s approx.

N330 M30

Note

The variable $AC_TIME contains the time from the start of the block in seconds. It can only

be used in synchronized actions.
