2
Operation 10.04
2.10 Automatic mode
2
ï›™ Siemens AG, 2004. All rights reserved
2-124 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Specify target directly
îš¾ Load a program in "Machine Auto" operating mode (see Sec.
"Selecting a program for execution").
Search
pointer
îš¾ Press the "Block search" and "Search pointer" softkeys.
îš¾ Specify the desired target.
To
endpoint
...
External -
without cal.
îš¾ Select a calculation technique.
Cycle Start
îš¾ Press the "Cycle Start" key.
ShopMill carries out all necessary default settings.
Cycle Start
îš¾ Press the "Cycle Start" key again.
The new starting position is approached. The program executes from
the beginning or end of the target block, depending on the calculation
technique.
Reset
You can abort the search by pressing the "Reset" key.
Search for any text
îš¾ Load a program in "Machine Auto" operating mode (see Sec.
"Selecting a program for execution").
Search
îš¾ Press the "Block search" and "Search" softkeys.
îš¾ Enter the text string that you want to locate.
îš¾ Select whether the search is to commence at the start of the
program or the current cursor position.
Search
îš¾ Press the "Search" softkey.
The program block that contains the text string is marked.
Continue
search
îš¾ Press the "Continue search" softkey, if you want to continue the
search.
Start
search run
îš¾ Press the "Abort" and "Start search run" softkeys.
îš¾ Where chained program blocks have several technology blocks,
select the desired technology block in the "Search run" window
and press the "Accept" softkey.
The prompt does not appear in the case of single program blocks.
