Siemens SINUMERIK 840D Operation/Programming

3
Programming with ShopMill 10.04
3.7 Drillin
g
3
 Siemens AG, 2004. All rights reserved
3-230 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
3.7 Drilling
Programming holes and
threads
In ShopMill, first program the technology blocks in the exact order in
which they need to be performed, e.g.
1. Centering, with tool and input of spindle speed and machining
feedrate
2. Deep-hole drilling, with tool and input of spindle speed and
machining feedrate
3. Tapping with tool and input of spindle speed and machining
feedrate
Once you have programmed the technologies, you need to enter the
position data. ShopMill provides various positioning patterns (see
Sec. "Positions").
This sequence, first technology block and then positioning block must
be adhered to in drilling cycles.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
