4-318 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
4.1 Creating a G code program
If you do not want to program with the ShopMill functions, you can
also generate a G code program with G code commands in the
ShopMill user interface.
You can program a G code command according to DIN 66025.
In addition, the parameter screens offer support for measuring and
programming contours, drilling and milling cycles. G code is
generated from the individual forms, which you can recompile back to
the screen forms. The measuring cycle support function must be set
up by the machine manufacturer.
Please refer to the machine manufacturer's instructions.
For a detailed description of G code commands to DIN 66025, and of
cycles and measuring cycles, please refer to:
References: /PG/, Programming Guide Fundamentals
SINUMERIK 840D/840Di/810D
/PGA/, Programming Guide Advanced
SINUMERIK 840D/840Di/810D
/PGZ/, Cycles Programming Guide
SINUMERIK 840D/840Di/810D
/BNM/, User Manual Measuring Cycles
SINUMERIK 840D/840Di/810D
You can call up context-sensitive help, if you require more information
on particular G code commands or cycle parameters on the PCU 50.
For a detailed description of the online help, please refer to:
References: /BAD/, Operator's Guide HMI Advanced
SINUMERIK 840D/840Di/810D
Creating a G code
program
îš¾ Press the "Program" softkey.
îš¾ Select the directory in which you want to create a new program.
New
G code
program
îš¾ Press the "New" and "G code program" softkeys.
îš¾ Enter a program name.
Program names may be a maximum of 24 characters in length.
You can use any letters, digits or the underscore symbol (_).
ShopMill automatically replaces lower case with upper case.
