Siemens SINUMERIK 840D Operation/Programming

2
10.04 Operation
2.10
A
utomatic mode
2
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-131
2.10.10 Simultaneous recording during machining
You can track the current machining operation on the machine tool
simultaneously by monitoring the graphic display on the control
screen.
Precondition
Program test and dry run feedrate must not be selected.
Simultaneous recording is a software option.
Press the "Real-sim" softkey and
Cycle Start
start the program with "Cycle Start".
The "simultaneous recording" function can be switched on at any time
during machining.
An explanation of the functions available under "Simultaneous
recording" can be found in Secs. "Simultaneous recording before
machining" and "Simulation".

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
