10.04 Operation
2.13 Tools and tool offsets
2
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-159
Relocate
 Press the "Relocate" softkey.
The "Empty location" window appears. The "Location" field is
initialized with the number of the first empty magazine location.
 Press the "OK" softkey to relocate the tool to the suggested
location.
-or-
 Enter the location number you require and press the "OK" softkey.
-or-
Spindle
 Press the "Spindle" and "OK" softkeys to load a tool into the
spindle.
The tool is relocated to the specified magazine location.
Finding an empty
location
 Select the "Magazine" softkey in the "Tools WOs" operating area.
 Place the cursor on the tool that you wish to relocate to a different
magazine location.
Relocate
 Press the "Relocate" softkey.
The "Empty location" window appears. The "Location" field is
initialized with the number of the first empty magazine location.
 Enter the magazine number and a "0" for the location number if
you wish to search for an empty location in a particular magazine.
-or-
 Enter a "0" for the magazine number and location number if you
wish to search for an empty location in all magazines.
 Press the "OK" softkey.
An empty location is suggested.
 Press the "OK" softkey.
The tool is relocated to the suggested magazine location.
