Siemens SINUMERIK 840D Operation/Programming

0
10.04 Contents
0
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition xvii
9.2 Example 2: Translation and mirroring of a contour................................................. 9-426
9.3 Example 3: Cylinder surface transformation........................................................... 9-429
9.4 Example 4: Slot side compensation........................................................................ 9-433
9.5 Example 5: Swiveling.............................................................................................. 9-437
Appendix A-445
A Abbreviations ..........................................................................................................A-446
B References..............................................................................................................A-449
C Index ........................................................................................................................ I-461

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
