Siemens SINUMERIK 840D Operation/Programming

3
10.04 Programming with ShopMill
3.3 Creatin
g
a se
q
uential control
p
ro
g
ram
3
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 3-183
Opening the program
editor

Select a program.
 Press the "Expansion" key.
The softkeys for the program editor are displayed in the vertical
softkey bar.
Selecting a program
block
 Place the cursor in the machining plan on the first or last block
you want to select.
Mark
 Press the "Mark" softkey.
 Use the cursor keys to select any further program blocks.
The program blocks are marked.
Copying a program
block
 Select the program block(s) in the machining plan.
Copy
 Press the "Copy" softkey.
The program blocks are copied into buffer memory.
Cutting a program block
 Select the program block(s) in the machining plan.
Cut
 Press the "Cut" softkey.
The program blocks are removed from the machining plan and stored
in buffer memory.
Pasting a program block
 Copy or cut the desired program blocks in the machining plan.
 Place the cursor on the line after which the program block(s) is
(are) to be inserted.
Insert
 Press the "Insert" softkey.
The program blocks are inserted in the machining plan of the
program.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
