3
Programming with ShopMill 10.04
3.5 Contour millin
3
ï›™ Siemens AG, 2004. All rights reserved
3-218 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
8. Contour spigot 1
9. Clear residual material spigot 1
10. Contour blank 2
11. Contour spigot 2
12. Clear residual material spigot 2
The "Residual material" function is a software option.
Spigot Res.
Mat. >
îš¾ Press the "Cont. mill." and "Spigot Res. Mat." softkeys.
All
parameters
îš¾ Press the "All parameters" softkey if you want to enter additional
parameters.
Parameters Description Unit
T, D, F, S, V See Sec. "Creating program blocks".
Machining
type
Roughing
TR Reference tool for residual material
D Cutting edge of reference tool (1 or 2)
Z0
Z1
DXY
DZ
UXY
UZ
Reference point in Z direction (abs.)
Depth with reference to Z0 (abs. or inc.)
Maximum infeed in the XY plane
Plane infeed in %: Ratio of plane infeed (mm)
to milling cutter diameter (mm)
Maximum depth infeed (Z direction)
Finishing allowance in plane
Finishing allowance in depth
mm
mm
mm
%
mm
mm
mm
Retraction
mode
If more than one approach point is necessary, specify the retraction height to which
the tool retracts between approach points.
• To retraction plane
• Z0 + safety clearance
If there are no spigots or other elements larger than Z0 in the machining area, "Z0 +
safety clearance" can be selected as the retraction mode.
