Siemens SINUMERIK 840D Operation/Programming

1
Introduction 10.04
1.2 Workstation
1
 Siemens AG, 2004. All rights reserved
1-26 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
OP 012 operator panel
1
7A2
A3
A4
A2
A4
6
A5
OP 012 operator panel
1 12" screen
2 Screen keys
3 Horizontal softkey bar
4 Vertical softkey bar
5 Alphanumeric keypad
Correction/cursor pad with control keys and input key
6 USB interface
7 Mouse
Operator panel OP 015
1
5
A2
A3
A4
A2
Operator panel OP 015
1 15" screen
2 Screen keys
3 Horizontal softkey bar
4 Vertical softkey bar
5 USB interface

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
