Introduction 10.04
1.2 Workstation
1
 Siemens AG, 2004. All rights reserved
1-28 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Ctrl
Use the following key combinations to navigate in the process plan
and in the G code editor:
• Ctrl + Home: Jump to the beginning.
• Ctrl + End: Jump to the end.
Alt
Irrelevant in ShopMill.
Del - not with OP 031
• Deletes the value in the parameter field.
• In insertion mode, it deletes the character marked by the cursor.
Insert
Activates insertion mode or the pocket calculator.
Input
• Terminates entry of a value in the input field.
• Opens a directory or program.
Alarm - only OP 010 and OP 010C
Opens the "Messages/Alarms" operating area.
This key has the same function as the "Alarm list" softkey.
Program - only OP 010 and OP 010C
Opens the "Program" operating area.
This key has the same function as the "Prog. edit" softkey.
Offset - only OP 010 and OP 010C
Opens the "Tools/Offsets" operating area.
This key has the same function as the "Tools WOs" softkey.
Program Manager - only OP 010 and OP 010C
Opens the "Program Manager" operating area.
This key has the same function as the "Program" softkey.
