Changing the orientation
in 3D
You can rotate the graphics in the X, Y, or Z axis direction.
Details
Rotate
 Press the "Details" and "Rotate" softkeys.
Up
 Press the "Up" softkey.
- OR -
Down
 Press the "Down" softkey.
- OR -
Left
 Press the "Left" softkey.
- OR -
Right
 Press the "Right" softkey.
- OR -
 Press one of the cursor keys.
You can see the result of the rotate command in the coordinate
system in the lower left corner.
Accept
 Press the "Accept" softkey.
The commands are applied and the visualized workpiece is shown
with its new axis orientation.
