6
File Management 10.04
6.3 Pro
ram mana
ement with PCU 50
6
ï›™ Siemens AG, 2004. All rights reserved
6-374 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Running a G code program
from floppy disk or network
drive
îš¾ Open the Program Manager.
...
îš¾ Select the floppy disk/network drive via the appropriate softkey.
îš¾ Place the cursor on the directory that contains the G code
program you want to execute.
-or-
îš¾ Press the "Input" or "Cursor right" key.
The directory opens.
îš¾ Place the cursor on the G code program you want to execute.
Continue
>
Exec. from
hard disk
îš¾ Select the "Continue" and "Exec. from hard disk" softkeys.
ShopMill switches to "Machine Auto" mode and uploads the G code
program.
Cycle Start
îš¾ Press the "Cycle Start" key.
Workpiece machining is initiated (see also Sec. "Automatic mode").
The program contents are loaded continuously to the NC main
memory while the program is being processed.
