Siemens SINUMERIK 840D Operation/Programming

6
File Management 10.04
6.3 Pro
g
ram mana
g
ement with PCU 50
6
 Siemens AG, 2004. All rights reserved
6-384 SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition
Replace all
 Select the "Replace all" softkey to import all tool data. Any
existing tools will now be overwritten without a warning prompt.
-or-
Replace
none
 Select the "Replace none" softkey if you want to cancel the data
import.
-or-
 Select the "No" softkey if you want to keep the old tool.
If the old tool is not at the saved magazine location, it is relocated
there.
-or-
 Select the "Yes" softkey if you want to overwrite the old tool.
With the tool management option without loading/unloading, the old
tool is deleted; the old tool is unloaded beforehand in the variant with
loading/unloading.
If you change the tool name before importing it with "Yes", the tool will
be added as an extra tool to the tool list.
Work offsets
Existing work offsets are always overwritten when new offsets are
imported.
Magazine loading
If magazine loading data are not imported at the same time, tools are
entered in the tool list without a location number.


Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
