Siemens SINUMERIK 840D Operation/Programming

9
10.04 Examples
9.5 Exam
p
le 5: Swivelin
g
9
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 9-439
3. Swiveling
• Select via the
Transfor-
mations >
Swiveling
>
softkeys
• Example of technological data:
T MILL_4 D 1
• Enter the following parameters:
Retraction
Yes
Swiveling
Yes
Transformation
New
X0
0
Y0
-50
Z0
0
Swiveling
Axis by axis
X
90°
Y
0°
Z
0°
X1
0
Y1
0
Z1
0
Direction
-
•
4. Rectangular pocket
• Select via the
Pocket
>
Rectang.
pocket
softkeys
• Example of technological data:
T MILL_4 D 1 F 0.1 mm/tooth V 200 m/min
• Enter the following parameters:
Position of
reference point
Center
Machining type
Roughing
Type of position
Single position
X0
-25 abs
Y0
-25 abs
Z0
0 abs
W
10
L
20
R
2
α0
45°
Z1
5 inc.
DXY
3 mm
DZ
2.5
UXY
0 mm
UZ
0
Insertion
Center
FZ
0.05 mm/tooth
Remove stock
Complete mach.
