10.04 Appendix
B References
A
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition A-453
/PFT6/
SIMODRIVE 611, MASTERDRIVES MC
Planning Guide Synchronous Servomotors 1FT6
/PFU/
SINAMICS, MASTERDRIVES
MICROMASTER
SIEMOSYN Motors 1FU8
/PHC/
SINUMERIK 810D
Configuring Manual (HW)
/PHD/
SINUMERIK 840D
Configuring Manual (HW)
/PJAL/
SIMODRIVE 611, MASTERDRIVES MC
Planning Guide Three-Phase Servomotors
General Part for 1FT / 1FK Motors
/PJAS/
SIMODRIVE 611, MASTERDRIVES VC/MC
Planning Guide Asynchronous Motors
Contents: General Part, 1PH2, 1PH4, 1PH7, 1PL6
/PJFE/
SIMODRIVE
Planning Guide 1FE1 Built-In Synchronous Motors
Three-Phase AC Motors for Main Spindle Drives
/PJF1/
SIMODRIVE
Installation Guide 1FE1 051.-1FE1 147. Built-In Synchronous Motors
AC Motors for Main Spindle Drives
/PJLM/
SIMODRIVE
Planning Guide 1FN1, 1FN3 Linear Motors
ALL General Information about Linear Motor
1FN1 1FN1 Three-Phase AC Linear Motor
1FN3 1FN3 Three-Phase AC Linear Motor
CON Connections
/PJM2/
SIMODRIVE 611, MASTERDRIVES MC
Planning Guide Servomotors
Contents: General Part, 1FT5, 1FT6, 1FK6, 1FK7, 1FS6
/PJTM/
SIMODRIVE
Planning Guide 1FW6 Built-In Torque Motors 1FW6
/PJU/
SIMODRIVE 611
Planning Guide Converters
/PKTM/
MASTERDRIVES
Planning Guide Torque Motors 1FW3
/PMH/
SIMODRIVE Sensor
Configuring/Installation Guide
Hollow-Shaft Measuring System SIMAG H
/PMH2/
SIMODRIVE Sensor
Configuring/Installation Guide
Hollow-Shaft Measuring System SIMAG H2
