2
10.04 Operation
2.6 Measurin
work
iece zero
2
ï›™ Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 2-73
Save P1
9. Press the "Save P1" softkey.
The coordinates of the first measuring point are measured and stored.
Save P2
Save P3
10. Reposition the spindle holding the tool each time, approach
measuring points P2 and P3 and press the "Save P2" and "Save
P3" softkeys.
Save P4
11. Repeat the procedure to measure the fourth measuring point
when you measure "any corner".
Set WO
-or-
Calculate
12. Press the "Set WO" or "Calculate" softkey.
The corner point and angles α and β are calculated and displayed.
With "Set WO", the corner point now corresponds to the position
setpoint. The calculated offset is stored in the work offset.
Measuring a right-
angled/any corner
automatically
1. Attach a 3D probe type tool to the spindle.
2. Prepare the measurement (as described under "Measuring a right-
angled/any corner manually", steps 2 to 7).
3. Move the tool up close to measuring point P1.
Cycle Start
4. Press the "Cycle Start" key.
This starts the automatic measuring process. The position of
measuring point 1 is measured and stored. The "P1 stored" softkey
becomes active".
5. Repeat the measurement procedure (steps 3 to 4) to measure
points P2 and P3.
6. If you are measuring a corner not equal to 90°, repeat the
procedure to measure and store point P4.
Set WO
-or-
Calculate
7. Press the "Set WO" or "Calculate" softkey.
The corner point and angles α and α are calculated and displayed.
With "Set WO", the corner point now corresponds to the position
setpoint. The calculated offset is stored in the work offset.
